Saffron Technical Institute: ww.oti1.com

Laptop chip level repairing course Rs.10,000/-
Desktop motherboard chip level Rs.5000/-
Mobile chip level Rs.5000/-
For more course updates,final fees and free hostel facility details visit: www.oti1.com
Total fee Rs 20,000/- (Rs.7500 discount on combined course)

Special offer for Limited period:

Lowest Price total in INDIA for 3 Chip level courses :

Discount on combine course Rs 7,500 (Limited period offer).
Lowest Price total in INDIA for 3 Chip level courses:
Laptop & Desktop Motherboard chip level training Rs.12,500 + mobile repairing chip level course includes for Free.(Service Tax Includes in fees, ON ONE TIME PAYMENT)
Note: For final fees check www.oti1.com
Batch Timings :- Student can continue for extra days on topic not cleared (no extra charges applied).

1)Weekend Sunday (full day) batch.
Duration : 12days
Timing : From 11am

2) Regular course (full day) batch
Duration:12 days
Timing: From 11am
Guaranteed Practical from first day. No writing work.

Company profile:

We are one of the best for 100% practical training with adequate equipment, and training facility for laptop repairing course in Thane Navi Mumbai, India with hostel facility.
We have developed precise training methods specifically designed for the youth, undergraduates, graduates, postgraduates from engineering and non-engineering background enabling them to make a career in the Circuit (Laptop, Desktop Motherboard, Mobile and Printer) repairing business. No electronics or technical background needed.

Join now to become an expert Laptop Chip level repair engineer.

1) Free life time Technical support after completion of course.

2) General Consultancy for Centre Setup.

Our Aim:

1) Our main orientation is towards practical training.
2) We aim to provide skilled and professional technicians

1) Laptop & Desktop Repairing Courses Syllabus:

LEARN CHIP LEVEL LAPTOP TRAINING BOTH BASIC AND ADVANCE :

Laptop Chip level Repairing Course includes :

1) Basic electronics and micro components
2) Introduction and determining values of SMD(Surface Mounted) components: resistors, condensers, Semiconductor diodes and Zener diodes, PNP and NPN transistors, N-Channel and P-Channel mosfets, N-Channel and P-Channel Power Trench mosfets,resistor colour coding system
3) The basic fundamentals of a laptop
4) Difference between the working of a laptop, netbook and desktop computer
5) Upgrading memory modules like RAM, harddisk& BIOS
6) BIOS settings of different laptops: As AWARD, AMI, INTEL, MITSUBISHI, HYUNDAI, SST, WINBOND, PHOENIX, etc.
7) Power management of a laptop
8) Diagnosing problems without disassembling a laptop
9) Expert guidance and procedures of repairing a laptop
10) Assembly and disassembly of different laptops with video guidance
11) Testing of batteries and power adaptors
12) Technique of using Cathode Ray Oscilloscope(CRO) and Multitester
13) Installation of Drivers for various Operating Systems which do not come with the system upon identification of chips
14) Repairing Human Interface Devices (Keyboard, Touchpad, Trackball etc.)
15)Block diagrams and schematic diagrams of different laptops
16) Replacing Mobile Processor, FPC belts, DVI cables, switches, speakers, web cams, ventilation fans, Bluetooth cards, WI-FI cards, WI-FI antenna cables of laptop motherboards
17) Repairing LCD display and Inverter circuit of laptops
18) Identification of all chips and crystals on the motherboard
19) Basic electronics and microcomponents: Resistors, capacitors, diodes, transistors, mosfets, inductors, Power trench mosfets, fuse, connectors, and coils
20) Track tracing and jumpering
21) Detailed component list and working of various sections of a laptop motherboard:
22) As PWM section, volt IN section, CPU temperature sensing and control section, Audio codec-amplification-headphone-HDA section, Charging-Discharging section, Step-Down section, Graphics section, System controller, Embedded controller, input-output section
23) Datasheet reading and testing: As VDD, VCC , PCICLK, VID, Power Good, X-in, X-out, USB_48MHZ, REF, VSS, VIN, V+, VBAT, etc.
24) Testing of chips using Datasheet
25) Replacing of faulty chips using Rework Station
26) Testing Frequencies of circuit and crystals using Cathode Ray Oscilloscope(CRO)
27) Notes and course material with pictures and videos created on the basis of actual practical experience (available in soft copy and hard copy)
28) Complete fault finding diagnostics and sure-shot solutions
29) Testing Data Addresses on RAM, BIOS, PCI by using CRO
30) Repairing SO-DIMM RAM stick by replacing chips on the RAM stick
31) 2.5" SATA and IDE Harddisk repairing
32) Repairing of CD-ROM
33) Detailed numbering of all the chips of the laptop,

For example:1) POWER SUPPLY CHIP. 2) IO CHIP.3)CPU power supply chips.4)Charge discharge control chip.5)CPU temperature control chip.6)Graphics Brand.7)Ethernet chips.8) Sound audio Chip .9)PC Card Chip.10)PC Card Chip.11)Keyboard-chip. 12)Battery IC.13)Memory control chip.14) Clock IC.15) lcd back light control. 16) Ddr memory power supply. 17) Ddr memory power.supply. 18)Other Common chips.

Mobile Repairing Courses Syllabus:

Chip level Mobile repairing course.
No electronics, Education Qualification or Technical Background needed.
Course Details: RS 5000/-

Batch Timings:-
1)1) Regular course Morning 2 hours.
Duration: 12 to 15 days.
Timing: From morning 8am to 10am.

2) Weekend Sunday not Available for mobile course..
Note:1] No extra charges are applied for extra period of 15 days for regular batch.

2) Mobile Chip level Repairing Course includes :

HARDWARE:

1) Basic electronics and microcomponents:
Introduction and determining values of SMD(Surface Mounted) components: resistors, condensers, Semiconductor diodes, PNP and NPN transistors, N-Channel and P-Channel mosfets, connectors, coils, fuse etc.
2) The basic fundamentals of a Mobile Phone
3) Diagnosing problems without disassembling mobile Phone
4) Expert guidance and procedures of repairing mobile phone
5) Assembly and disassembly of different mobile phones
6) Testing of batteries and battery chargers
7) Technique of using Rework station, solder iron, external charger and Multitesters
8) Repairing Human Interface Devices (Keyboard, Touchpad, Trackball etc.)
9) Block diagrams and schematic diagrams of different mobile phones
10) Replacing LCD displays and FPC Belts of mobile phones
11) Identification of all chips and crystals on the mobile PCB board
12) Track tracing and jumpering
13) Detailed component list and working of various sections of a laptop motherboard:
As Power section, Charging section, CPU, Audio section, Network section, Display section, light section, Keypad section, etc.
14) Replacing of faulty chips using Rework Station
15) Notes and course material with pictures and videos created on the basis of actual practical experience (available in soft copy and hard copy)

SOFTWARE:

1) Installation & Function of Flasher Software
2) Selection & Installation of EEPROM Files
3) Unlocking of Phone Codes
4) Formatting of Internal Memory
Documents:
1) One Passport size photo.
2) 2) Certificate ID proof (Any Educational LC Or Birth Certificate and Voter ID card Or Adhar Card).
Note :* Candidate should carry original document at the time of submitting, Xerox™ copy.
